NEW Beta Enduro 400/450/525 click here

2008 Beta Alp 200

2008 Beta Alp photos

New model 200 Alp

New chassis - slim & light.

Quickly converts to trials spec.

Everything unbolts including seat & tank cover - see pics above.
Beta have done a really good job on this Mk2 Alp 200. Its lighter, slimmer and is easy to change to a more trial style set-up. All the "street stuff" unbolts.  Suspension seems softer,
particularly the rear which a great improvement. This one came with Pirelli MT43s fitted and an extra grafics kit for the trials mudguard that lives under the saddle.
200cc Suzuki electric start engine.
More info soon .......£t.b.a.

2008 Beta Alp 4.0

Beta presents the new Alp 4.0, a real factotum-vehicle. This 100% versatile bike is approved for mounting, both enduro tyres (on production models) for amazing trips on the paths through mountains and woods, or road tyres to bite the traffic of the town.

Its engine is a real 350cc 4-stroke classic: simple and created to last, absolutely reliable and perfectly faithful to the 4.0’s nature: excellent performances with no excessiveness.

Even the frame respects this principles: a solid steel chassis, simple and essential and an adjustable rear shock absorber assuring a good comfort on every roadbed. The disk brakes with a double-piston calipers assure a reliable and vigorous breaking. For this year it is even newer and more exciting: plastics with a new modern and sophisticated design, a new better-looking and more efficient headlamp unit, a new exhaust system, and two brand new paint-and-graphics schemes for 2008: White Pearl, Orange-Gray

---

07 Beta Rev-3 Enduro & Alp

Latest price list & offers here (pdf file)
2006 Beta Alp 200/350

2006 Alp 4.0 (350 suzuki engine)

Coming soon the all new Alp 4 - a 350cc trailbike or supermoto (Motard 4) using the air cooled Suzuki DR350 engine -

FRAME FEATURES   Frame iron double closed cradle  Wheel base mm:  1410  Overall length mm:  2185  Overall width mm:  860  Overall height mm:  1230  Seat height mm:   865  Ground clearance mm:   300  Footrest height mm:    350   Dry mass kg:  133  Fuel capacity lt:      10,5  Reserve lt.      3,0  Front fork Hydraulic fork, 46 mm tubes   Rear suspension single shock with adjustable spring  Shock absorber stroke mm:    83   Front wheel travel mm:  210  Rear wheel travel mm:  200  Front brake disk  ø mm  260   Rear brake disk ø mm   220   Front rim  1,85 x 21   Rear rim  3,00 x 18  Front tyre  1,85 - 21  (90/90 - 21) 54 R  Rear tyre  3.00 - 18  (140/80 - 18) 70 R    3.00 - 18  (130/80 - 18) 66 R

ENGINE FEATURES   Producer: SUZUKI Single cilinder, 4 stroke, air cooled, camshaft  Bore 79,0 mm  Stroke 71,2 mm  Displacement 349 cc  Compression ratio 9,5:1  Carburetor Mikuni BST 33  Feeding Unleaded gasoline  Starter Electric   Lubrification system forced lubrication with pump  Valves 4  Ignition Electronic  Spark plug NGK CR9EK - DENSO U27ETR  Clutch Multiple disc clutch in oil bath  Primary trasmission 15/48  Gear Box 6 speed  Engine oil (type-quantity) Sint Motocompetition (850)

some more pictures here: & here

2002 Beta info

2001 Mini Trial 50

2001 Rev-3

2000 Rev-3

John Lampkin's SSDT Beta prep guide
