Gas Gas
Supermoto
04
Gas Gas press release
Larger Gas Gas images
available
here
Gas Gas Supermoto 04
Hot news - 04 SM450 goes blue!......well the Press Release said so, but the pic they sent seems to be a very very dark blue!!
The first model is now available and its the 250SM (two stroke).
Gas Gas Press release:
THE NEW SUPERMOTARD: DERIVING
FROM ENDURO FOR A MORE URBAN USE
At the Motoshow 2001, GAS GAS will carry out the international presentation of the new Supermotard range (SM), with four new engines: 50 cc, 125 cc, 300 cc all of them with a single-cylinder 2-stroke engine, and the 400 cc 4 stroke.
All these bikes have in common the same colour -dark grey with silver streaks which stress the aesthetic shape of the panels which wrap the fuel tank, slightly prolonged below the seat- and design, and the fact that they start from the same predecessor: their chrome-molibdenum steel frames and engines derive directly from the Enducross range, with six-speed gearbox and hydraulically-driven multi-disc clutch.
Their aspect, in any case, is
not
similar at all to the enduro range. At first sight, the new SM shows
significant
changes. The most remarkable one is the wheels: the Supermotard feature
wide
tyres with very low profile on 17’’ duraluminium spoke rims. These are
high-performance road tyres. A first glance will also display aesthetic
differences in the front mudguard, much slimmer and flat than the ones
fitted in the Enducross.
A closer look at the wheels shows
another significant change: the front brake calipers, with two pistons
in the smallest bike -the 50cc- and four in the rest, derived from
competition
and with larger, big- diameter discs -260mm in the 50cc and 310mm in
its
larger sisters-. The use of this high-quality material in the brake
discs
ensures the performance of the front brake on tarmac.
Aluminium swingarm, suspension with multiple adjustment possibilities, upside down front fork and progressive system with Öhlins shock absorber at the rear (Boge in the 50cc); and a very compact and solid appearance make this a quality product wherever you look. The exhaust pipe has also been modified.
Naturally, the new SM’s suspensions are set harder, with smooth riding on asphalt. That is because the new range has been designed with city use in mind, and for all kinds of public: from teenagers who ride the 50cc and start identifying themselves with GAS GAS, to adults who need to move around the towns swiftly, with motorbikes ranging from 125cc -very easy to ride- up to 400cc, and with power outputs up to 50.6 bhp at 7,340 rpm in the highest-size 2-stroke engine.
It is remarkable that the new
range
has already been tested in competition with great results, with Daniel
Crosset at the handlebars of an SM taking part in the Belgian
Supermotard
Championship.
4-STROKE GAS GAS ENGINE. WHY?
When GAS GAS finished deveolping their new enduro motorbike with their own 2-stroke 250cc engine, procedures were started at once to commercialise it in Europe and the rest of the countries where the manufacturer exports.
The research department started to develop different technical solutions applicable to the production process, adapting the bike so that it would meet the EEC 97/24 noise level regulation (chapter 9), which sets the maximum in 80 dB (A) at of the engine speed where the maximum power is achieved (this corresponds to 50k/h in third gear).
However, the most difficult part of the regulation was for a 2-stroke engine to meet the emission levels (chapter 5). The European standards regulations set the maximum levels at 8 g/km CO, 4 g/km of unburnt hydrocarbons and 1g/km of Nitric Oxide per cycle.
For a 2-stroke engine to meet these requirements it was necessary to fit the motorbike with a catalyst in the exhaust pipe.
This, together with the fact that the market welcomed the use of small or medium-size single-cylinder engines for their use in off-road bikes and that more and more countries were using the emissions levels to stop 2-stroke engines from entering their markets, was central in the decision to develop 4-stroke engines.
Specs:
Gas Gas SM400FSE
90 x 62.6 mm bore/stroke.
fuel injection by Magneti Marelli,
6 gears,
poke: 47 bhp @ 9940 rpm
grunt: 4.4 mkg @ 6570 rpm
Frame: deltabox cromoly, alloy
swingarm.
USD forks, WP or Marzocchi 295mm
travel
Rear Shock, Ohlins 320 mm travel
Nissin brakes.
1475mm wheelbase.
900mm seat height
9.5 litre tank.
SM400
rear view
Gas Gas SM250 2003 ,
....more
pics here
Specs: 249.3 cc , 66.4 x 72mm
Liquid cooled two stroke with
exhaust
valve.
Keihin PWK 38mm carb.
Kokusan digital multispark
ignition.
6 speed gearbox.
49.84 hp @ 8699 rpm
4.65 mkg@7628 rpm
Same running kit as 400.
